Firmware Versions

The COBRA firing systems ecosystem consists of many devices including the 18R2, 18M, 36M, 72M, 6M, and Audio Box. Firmware is the embedded software in our hardware that gives life to the device. COBRA is continually striving to improve products, and as we add feature enhancements to each device, COBRA releases new firmware versions to support the newly added functionality. While some new features may not always be available for older hardware, all COBRA systems support the latest firmware versions within our universal system design where all systems work happily together as a single family of products.

In addition to performing firmware updates to hardware firmware, COBRA also performs software upgrades to the COBRA Control Panel Android app available online from Google Play.

To determine compatible firmware versions across the COBRA Firing Systems equipment portfolio please see Firmware Figured Out.

To perform a firmware upgrade or downgrade please download the COBRA reprogramming software.

Below is a list of the current beta and stable firmware releases for your COBRA system. To learn more about our firmware release process, see What is our firmware release process?

Additional support is always available via email at help@cobrafiringsystems.com.


COBRA Firmware Stable Release Candidates

Version Number Release date Release Notes
December 6th, 2021

- Added scripting error code 57 to prevent the use of STEP events when using SMPTE Timecode.

- Fixed a rare issue where 18R2s would not allow syncing new modules.

- Fixed a script loading issue that could occur on some Command Center units.

- Fixed a very rare issue that could cause more than one cue to fire simultaneously.

- Improved Audio Box playback timing.

COBRA Firmware Stable Releases

Version Number Release date Release Notes

View Release Notes ]

April 2014 Major New Improvements

- Manually fire cues while the script is running

- Reinforced wireless security

- Fire multiple scripts without disarming

Minor Improvements

- Synchronization process change

- Audio accuracy

- 320k MP3 audio quality

- Sleep mode efficiency improved by 25%

- Manual AUTO-FIRE works past 12 seconds

Bug Fixes

- Sleep mode no longer displays backlight

August 2012

Major New Improvements

- Universal compatibility

- 1P low battery level warning

COBRA Firmware BETA Releases

Version Number Release date Release Notes
December 6th, 2021

18R2

- Fixed an issue where two cues on the same channel and firing at the same time could cause the module to not display in the arm count and fire.

- Added scripting error code 57 to prevent the use of STEP events when using SMPTE Timecode.

- Fixed a rare issue where 18R2s would not allow syncing new modules.

- Fixed an issue that caused DMX STEP scripts to not show correctly on the Control Panel.

- Fixed a display bug that showed the incorrect channel/cue on the 18R2 as being the last to fire.
- Fixed a module acknowledgment issue that prevented modules from showing in the arm count.
- Fixed incorrect scripting error code that was shown when a script had a cue fire time error.

36-72M

- DMX Events can now be disabled when using the Disable Firing feature on the 18R2.

- Fixed bug that prevented the 36/72M from showing on the Control Panel if you force refresh the module count while armed.

pMaqU7vXj89bAXLwxXha0EHd1551DfGlCw.png June 2021 6.0.5 is a patch release to 6.0.4 to address a few issues in 6.0.4.

18R2

- Fixes partial lock-up issues that could occur when changing the channels while a script is actively firing or paused.

-Fixed issue with alternate events causing ER33 on certain 18R2 hardware versions.

- Fixed issue with alternate events firing channel zero instead of correctly assigned channel.

- Scripts are now saved correctly on the 18R2 when power-cycling the remote after changing the script attributes from the Control Panel.

36-72M

- The modules will now send DMX zero values when in TEST or ARM if a DMX universe is set on the module. Previously the zero values were only sent while a script was running.

- Fixed minor display issues that caused text overlapped on the LCD while in program/sync mode.

May 2021 Major New Improvements
DMX Support
200 Channel / 3,600 Cue Support

Scripted Event Re-firing and Variable Pulse Times

Manual Hold to Fire

December 9th, 2020

5.1.2 is a patch release to 5.1.1 to address a few issues in the 5.1.1 firmware.

- 36M/72M in some cases displaying 18R2 signal strength vs. MESH signal strength

- Audio box hardware A may play audio slightly early by about 100-200ms

- Audio box in rare cases does not start audio

November 18th, 2020 Major New Improvements

- COBRA SMPTE Timecode


Minor Improvements

- 2x increase in device connection time

- Improved device count display

- Script comments

- Script filename is no longer limited to cobra.csv

- Audio filename limit increased to 45 characters

- 6M Support



Control Panel 2.2.0

- Edit script attributes

- Local Audio File Support

- Continuous clock

- Improved General Settings

- Unfired Product Email Report



COBRA Show Creator 1.2.0

- SMPTE Audio Player

- Combined Audio Files

- Script Comments

- Filename Improvements



Bug Fixes

- Fixed an issue where 18M hardware A modules may sleep and not wake up forcing the user to power cycle the 18M firing module

- In rare cases, module scripted firing timing may be off slightly due to minor calculation errors

- In some cases, when multiple modules were on and in program mode, the 18M may skip multiple addresses when synced

- In some cases, the control panel would crash and fail to open on Android 9.0

February 2017 Major New Improvements

- Manual and Scripted MESH

- 1/100th Second Timing

- 2nd Alternate Firing Button



Control Panel
- Field Map

- Offline Mode

Minor Improvements



Control Panel

- Improved Device List UI

- Improved Show Controls UI

- New Manual Firing UI



Bug Fixes

- 18R2 slow to load the final few modules in ARM mode

- 18M not waking up properly from sleep mode

-18M becoming stuck in a state of toggling between ARM and TEST mode (test and arm LED blinking back and forth)

- 18M not properly receiving the downloaded script from the 18R2

- 18R not firing channel 00 manually

- 18R in some cases has continuity disappear and re-appear momentarily

- Audio box incorrectly aligned when pressing the + and - buttons on the 18R2

- Minor audio box distortion upon pausing and resuming script

- 18R2 displaying incorrect -99 signal for modules

- 36/72M not displaying continuity in direct sunlight

- 36/72M not displaying continuity in direct sunlight

- Deadman button on the 18R2 could cause the script to not resume after being paused.

- 18R2 critical safety fix (only affected units sold from July 5th to July 24th, 2019)


View Release Notes ]

May 2015 Major New Improvements

- Alternate Event Firing

- Deadman Functionality



Control Panel

- COBRA Control Panel Integration

- Device List

- Show Controls

- Disable Firing Functionality



Minor Improvements

- Multiple Audio Files

- 30% More Battery Life

- Low Signal Warning

- Improved Low Battery Warning

- 18R2 Default Channel Changed to 00

- Force Un-Sync Removed from 18M

- Force Un-Sync Time Extended on 18R2 to 30 Seconds

- Loading script requires USB to be inserted at the time of 18R2 power up

- Script header arguments changed


Bug Fixes

- Manually fire cues while the script is running

- Reinforced wireless security

- Fire multiple scripts without disarming

April 2013

Major New Improvements

- Audio Box integration

- Unlimited channel firing



Bug Fixes

- Backlight stays on in sleep mode

- In some cases, testing continuity locally from the 18M will cause the 18M to re-start
